What is SCADA? Supervisory Control and Data Acquisition Explained
SCADA stands for Supervisory Control and Data Acquisition. A SCADA system is software and hardware that lets operators monitor and control an industrial process from a central location — collecting real-time data from field sensors and sending commands back to plant equipment.
Picture a control room with screens showing live data: temperatures, flow rates, pressures, tank levels, and alarm states — all in one place. That is a SCADA system in action.
If you manage a factory, water treatment plant, or power substation, a SCADA system is the dashboard that turns thousands of sensor readings into something a human operator can understand and act on.
The Four Core Components of a SCADA System
1. Field Devices (Sensors and Actuators)
These are the physical instruments attached to your process: temperature sensors, pressure transmitters, flow meters, valves, and motors. They are the source of all real-world data.
2. Remote Terminal Units (RTUs) or PLCs
RTUs and PLCs sit at field level, collect data from sensors, and execute control commands — closing a valve, starting a pump.
In modern systems, PLCs have largely replaced RTUs because of their processing power and programming flexibility.
3. Communication Network
Data travels from PLCs to the SCADA server via industrial communication protocols: Modbus, Profibus, DNP3, OPC-UA, or Ethernet/IP.
Which protocol depends on the age and type of your equipment. The network can be wired, wireless, or both.
4. SCADA Server and HMI Software
The server receives, processes, and stores data from all PLCs. The Human Machine Interface (HMI) displays this data graphically.
Operators use the HMI to issue commands, acknowledge alarms, and review historical trends. Popular platforms include Wonderware (AVEVA), Ignition (Inductive Automation), Siemens WinCC, and GE iFIX.
What Can SCADA Actually Do?
- Real-time monitoring — live visibility of all process variables across your entire plant
- Alarm management — instant alerts when parameters go out of range, with prioritisation and escalation
- Data historian — long-term storage of process data for trend analysis, compliance, and OEE reporting
- Remote control — operators can adjust setpoints or switch equipment from the control room without walking the plant
- Report generation — automatic shift, daily, and compliance reports pulled from historian data
Does Your Facility Need SCADA?
Not every automated facility needs a full SCADA system. A standalone machine with a simple HMI panel is fine when the process is self-contained.
SCADA becomes necessary when:
- You have multiple PLCs or control panels that need to be monitored together
- You need to record and analyse process data over time
- Your process spans multiple buildings, sites, or geographic locations
- Regulators or auditors require documented process records
- Alarm response time and escalation procedures need to be formalised
How Much Does SCADA Cost?
SCADA costs vary widely. The main drivers are tag count, software licence model, and whether hardware upgrades are needed.
As a general guide for UK projects in 2025:
- Small system (under 500 tags): £15,000 – £60,000 including software, engineering, and commissioning
- Medium system (500–5,000 tags): £60,000 – £250,000
- Large enterprise SCADA: £250,000+, often phased over multiple years
Open-source and subscription-based SCADA platforms (such as Ignition) can significantly reduce licence costs compared to traditional perpetual-licence software.
Next Steps
Evaluating whether SCADA is right for your facility? Or planning an upgrade from an ageing system?
For large-scale or multi-site processes, SCADA is often paired with a Distributed Control System (DCS) — which handles deterministic process control at field level while SCADA provides the supervisory layer above it.
